2.00mm Pitch Triple Row Female Header Connector 3x20P SMT Compatible Phosphor Bronze Socket

2.00mm Pitch Triple Row Female Header Connector 3x20P SMT Compatible Phosphor Bronze Socket

  • 2.00mm Pitch Triple Row Female Header Connector 3x20P SMT Compatible Phosphor Bronze Socket
  • 2.00mm Pitch Triple Row Female Header Connector 3x20P SMT Compatible Phosphor Bronze Socket
2.00mm Pitch Triple Row Female Header Connector 3x20P SMT Compatible Phosphor Bronze Socket
商品の詳細:
起源の場所: 広東省、中国
ブランド名: CNJWY
証明: ISO 9001:2015, RoHS, UL
モデル番号: CNJWY-FH200-3R20
お支払配送条件:
最小注文数量: 1000個
価格: USD 0.25-0.90 / Piece
パッケージの詳細: 静電気防止袋あたり 1000 個、輸出カートンあたり 10 袋
受渡し時間: 生産には7~15営業日、在庫品には3日かかります
支払条件: T/T,L/C 目の前で,ウェスタンユニオン,Paypal
供給の能力: 1 か月あたり 5000000 個
連絡先
詳細製品概要
ピッチ: 2.00MM 行: 三重の列
ポジション: 3×2~3×20 取付タイプ: 貫通穴、垂直
接点材質: リン青銅 接点のメッキ: ニッケル上のゴールドフラッシュ
絶縁体材料: PA6T、UL 94V-0 電流定格: 1接点あたり2A
定格電圧: AC250V 動作温度: -40℃~+105℃
ハイライト:

2.00mm Triple Row Header

,

3x20P Female Socket

,

Phosphor Bronze Contact

Two millimetre pitch is the compromise most compact controller designs settle on: noticeably smaller than 2.54mm, still robust enough for through hole assembly and hand rework. Adding a third row multiplies the available positions without lengthening the connector, so a 60 way interface fits into a body only 6.0mm wide. That combination is what makes this 2.00mm triple row female header useful in control boards that are already crowded with relays and terminal blocks.
